FEATURES
384 x 288 thermal resolution, high sensitivity detector, NETD < 35 mK (25°C,F# = 1.0)
Image processing technology: Adaptive AGC, DDE, 3D DNR
1024 x 768 resolution 0.39-inch OLED display
Supports distance measurement and hotspot function
Supports video recording and snapshot, built-in EMMC (16GB)
Supports digital zoom and cursor function, palettes of color adjustable
Up to 4.5 hours of continuous working
SPECIFICATIONS
THERMAL MODULE
Image Sensor: Uncooled Focal Plane Arrays
Maximum Resolution: 384 x 288
Frame Rate: 50Hz
Pixel Interval: 17m
Response Waveband: 8m to 14m
NETD: < 35mK (@ 25°C),F# = 1.0
Field of View: 10.0 x 8
Aperture: F1.0
Magnification: 2.14X
IMAGE DISPLAY
Display: 1024 x 768, 0.39-inch, OLED
Palettes: Black hot, white hot, red hot, fusion
Exit Pupil: 6mm
Eye Relief: 45mm
Observation Distance: 1235m
SYSTEM
Standby Mode: Yes
Uniformity Correction: Auto, Manual, External Correction
Storage: Built-in EMMC (16GB)
PIP: Yes
DPC: Yes
Hotspot: Yes
Digital Zoom: 1X, 2X, 4X, 8X
Hot Track: Yes
Distance Measurement:?Yes
POWER SUPPLY
Battery Type: Replaceable, Applicable type: CR123A, RCR123A
Battery Operating Time (with hotspot OFF): 4.5 hours
