OPERATING TEMPERATURE
Unfilled: -40 to 60°C
Glycerin filled: -20 to 60°C
MATERIAL
Bourdon Tube: SS 304, SS 316
Movement: SS 304
Pointer: Aluminum, Black
Media: Gas & Liquid
Connections: SS 316
Lens: Laminated Safety Glass
Dial: Aluminum, White, Black Lettering
Pressure Element: SS 306L / C-type
Ring: Bayonet Ring, Stainless Steel
Window: Laminated Safety Glass (NS 63: Polycarbonate)
Case & Cover: SS 304, IP65 Protection Stainless Steel, Blowout Back
FEATURES
Stainless Steel is used for Bourdon – Tube, Case, and Connection (High durability for corrosive pressurized fluids)
Bourdon – Tube and connection are Arc welded (Corrosive resistance is assured in all parts)
Full rotary movement and micrometer pointer for ease in calibration
Designed to run unfilled (dry) or with liquid (Glycerin) filled
Adjustable Screw on the needle for easy calibration
APPLICATIONS
Petrochemical Plants, Ships, Food Industry, etc
Power Plants (Thermal, Hydraulic & Nuclear Power Plant), Hydraulic & Pneumatic
Pure fluid (not contain any particle of solid or high viscosity), increased safety requirements for personal protection
For gaseous and liquid aggressive media that are not highly viscous or crystallizing, also in aggressive environments
Oil and gas industry, chemical and petrochemical industries, power engineering, and also water and wastewater technology
