Innovative EasyPulse technology, capable of generating lower jitter Square or Pulse waveforms, brings a wide range and extremely high precision in pulse width and rise/fall times adjustment
Plenty of analog and digital modulation types: AM, DSB-AM, FM, PM, PSK, FSK, ASK and PWM
Sweep and Burst function, Harmonics mode supported
High precision Frequency Counter
Standard interfaces: USB Device, USB Host, LAN (VXI-11), and GPIB (optional)
4.3 touchscreen display for easier operation
Siglent SDG2122X : 120MHz Function/Arbitrary Waveform Generator
Price : On Request
SIGLENT’s SDG2000X is a series of dual-channel function/arbitrary waveform generators with specifications of up to 120 MHz maximum bandwidth, 1.2 GSa/s sampling rate and 16-bit vertical resolution. The proprietary TrueArb & EasyPulse techniques help to solve the weaknesses inherent in traditional DDS generators when generating arbitrary, square and pulse waveforms. With advantages above, SDG2000X can provide users with a variety of high fidelity and low jitter signals, which can meet the growing requirements of complex and extensive applications.
Additional information
| Weight | 4000 kg |
|---|
