The FLIR E54 offers the resolution and sensitivity you need for basic condition monitoring, electrical/mechanical inspection, and building inspection. The 320 x 240 pixels thermal detector accurately measures temperatures up to 650C (1202F) and produces crisp, vibrant imagery that can be enhanced with patented FLIR MSX technology for added detail and perspective. The onboard FLIR Inspection Route runs pre-planned routes to help you stay organized when surveying large or multiple locations. FLIR Ignite provides automatic uploading of E54 images directly from the camera to the cloud for easy, secure storage and sharing.

SPECIFICATIONS

n

IR Resolution: 320 x 240 pixels
Thermal Sensitivity/NETD: <40mK at 30C (86F)
Accuracy: 2C (3.6F) or 2% of the reading
Storage Media: Removable SD card
Digital Camera: 5MP, with built-in LED photo/video lamp
Display: 4-inch, 640 x 480 pixels touchscreen LCD with auto-rotation
Operating Temperature Range:-15 to 50C (5 to 122F)
Storage Temperature Range:-40 to 70C (-40 to 158F)

n

IMAGING & OPTICAL

n

Color Palettes: Iron, Rainbow, Rainbow HC, White hot, Black hot, Arctic, Lava
Detector Type and Pitch: Uncooled microbolometer, 17 m
Digital Camera: 5MP, with built-in LED photo/video lamp
Digital Zoom: 1-4x continuous
f-number: 1.3
Focus:?Manual
Image Frequency: 30Hz
IR Resolution: 320 x 240 pixels
Lens Identification: NA
Minimum Focus Distance: 0.15m
Non-radiometric IR video streaming: H.264 or MPEG-4 over Wi-Fi MJPEG over UVC or Wi-Fi
Picture-in-Picture: Centered infrared area on the visual image
Radiometric IR video recording: Real-time radiometric recording (.csq)
Radiometric IR video streaming: Yes, over UVC
Spectral Range: 7.5-14 m:
Thermal Sensitivity/NETD: <40mK at 30?C (86?F)
UltraMax: No
Viewfinder: No

n
